Buy 3610RL-04W-B56 9025 12V 0.38A 9CM Server Fan CPU cooling fan, server fans. professional worldwide cooler fans distributor from this-is-maral.com
- Condition: Refurbished
- Origin: CN(Origin)
- Application: Computer Case
- Package: Yes
- Compatible CPU: yes
- Fan Life: 40000 hrs
- Lines: Photos
- Heatsink Material: Plastic
Brand: NMB-MAT
model: 3610RL-04W-B56
PN:453473-001
size: 92*92*25mm
voltage: DC12V
current: 0.38A
power: 4.56W
rotational speed: 1000-3500 RPM
air volume: 20.3-60.4CFM
noise: 20-47.6 dBA
wiring: the 4p interface of the main board supports speed measurement and PWM temperature control.
Bearing: high precision ball bearing
frame for fan: Injection Molding once, PBT + 30% glass fiber + VO grade flame retardant
fan blade: Injection Molding once, PBT + 30% glass fiber + VO grade flame retardant
fan rotation direction: from the direction of the fan blade, it is counterclockwise running
temperature:-20 degrees Celsius to +70 degrees Celsius storage temperature:-40 degrees Celsius to +80 degrees Celsius
bearing: high precision double ball bearing
power supply range: positive and negative 15% of rated power supply
insulation electronic resistance: greater than 500 megoo
withstand voltage: sink leakage current 0.5mA 500V/1 minute
working life: 100000 hours when the ambient temperature is 25 degrees
size: 92*92*25mm
voltage: DC12V
current: 0.38A
power: 4.56W
rotational speed: 1000-3500 RPM
air volume: 20.3-60.4CFM
noise: 20-47.6 dBA
wiring: the 4p interface of the main board supports speed measurement and PWM temperature control.
Bearing: high precision ball bearing
frame for fan: Injection Molding once, PBT + 30% glass fiber + VO grade flame retardant
fan blade: Injection Molding once, PBT + 30% glass fiber + VO grade flame retardant
fan rotation direction: from the direction of the fan blade, it is counterclockwise running
temperature:-20 degrees Celsius to +70 degrees Celsius storage temperature:-40 degrees Celsius to +80 degrees Celsius
bearing: high precision double ball bearing
power supply range: positive and negative 15% of rated power supply
insulation electronic resistance: greater than 500 megoo
withstand voltage: sink leakage current 0.5mA 500V/1 minute
working life: 100000 hours when the ambient temperature is 25 degrees
